Getting started
► Plug the supp lied USB 2.0 cable into the USB 2.0 (up stream) socket (8) and the
other end of the cable into a USB 2.0 socket on the computer.
Connect the USB keyboard and USB mouse directly to the PC, as the U SB connector
socket of the monitor is switched off in PC energy-saving mode.
A lock (Security Lock) can be mounted in the security slot to protect the monitor
against theft. A Security lock is not sup plied with the monitor.
Connecting cables to the computer
Information on the computer connections and interfaces is contained in the
operating manual for your computer.
► C onnect the data cable to the (active) m onitor port on the computer and secure
the plug-in connection by tightening the safety screws.
► In sert the other plug of the audio cable in the audio output of the computer.
► Plug the power connector of the monitor into a properly groun ded mains outlet.
► Plug the power connector of the computer into a properly grounded mains outlet.
If your computer has two monitor ports ("onboard" screen controller and separate
graphics card), the monitor port for the separat e graphics card is active as standard.
18 Fujitsu
