Fujitsu E22T-7 LED - Connecting the Monitor and Computer

Getting started
Connecting the device
Please observe th e safety information in "I mport ant notes", Page 7.
CE conformance and optimum picture quality are guaranteed only if
you use the data cables supplied.
► Switch off the monitor and the computer.
► Disconnect the power plug
from the computer.
Connecting cables to the monitor
The data cables supplie
d have two 15-p in D -SUB connectors or two 24-pin DVI
connectors for connect
ion to the monitor and to the computer.
Informationonthecom
puter connections an d interfaces is contained in the
operating m anual for
the compute r.
1
2
45673
1=Securi
ty slot for Security Lock
2 = Power connector
3=AUDIO
-IN socket
4 = AUDIO-OUT socket
5=HDMIso
cket
6 = DVI-D socket (DVI)
7=D-SUB
socket (VGA)
► Select the appropriate data cable for your co mputer.
