Operation
OSD menu functions
The OSD menu for analogue monitor operation is described below. Du ring
digital operation some functions are not available, as they are not required
due to the digital transmission technology used.
Adjusting the brightness and contrast
Call up the Brightness/Con
trast setting window
Brightness
Set the brightness of th e display
With this function yo u change the brightness of the backgroun d lighting.
Contrast
Set the contrast of the display
With this function you modify the contrast of bright colour tones.
Black level
Set the brightness of
the display
With th is function y
ou modify the contrast of dark colour ton es.
Auto level
Adjust the signal le
vel
With this function
you can automatically set the contrast.
The function is executed with the
button.
If the contrast
is set too high, bright surfaces can no longer be distinguished from very
bright surface
s. If the contrast is set too low, the maximu m brightness will not be achieved.
Adjusting the picture size and position
Call the Image adjust setting window
Phase
Eliminate picture disturbance
With this function you fine-tune your monitor to eliminate picture disturbance.
Clock
Set synchronisation
With this function you adjust the picture width to eliminate vertical picture
disturbances.
H-Position
Adjust the horizontal position
With this function you move the pic ture to the left or to the right.
V-Position
Adjust the vertical position
With this funct ion you move the picture up or down .
Expansion
Adjust the picture size
Full screen = selection of full screen mode
Keep aspect = maximum picture size without distortion
26 Fujitsu
