Operation
Changing the m onitor settings using the OSD menu
With the buttons on the control panel, you can call up and use the integrated
OSD (On-Screen Display) menu.
The English menu names are used in the following description (default s etting).
The OSD menu of your device may differ in several ways from
the functional scope described.
The softke
y icons may deviate from those s hown here.
► Press the
MENU
button to activate the OSD menu.
The OSD menu appears, with menu items for the s etting functions.
The first menu item (Brightness/Contrast) is highlighted and the associated
functions are visible in the right-hand menu field.
► Press
the
button o r button to highlight another icon (e.g. Image).
► Press the
button to select the highlighted icon.
The Image setting window will be displayed.
► Press the
button to close the OSD men u.
24 Fujitsu
