fi-5120C / fi-5220C Image Scanner Operator Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP

6.3RemedyingTypicalTroubles


Symptom: The scanning does not start.
Back
Did you unlock the shipping lock of the
flatbed?
(fi-5220C only)
NO
Turn OFF the scanner and unlock the shipping
lock. (*1)
YES
Are the document loaded correctly on the ADF
paper chute?
NO
Load document correctly on ADF paper chute.
YES
Is the ADF closed completely?
NO
Close the ADF completely.
YES
Is the interface cable connected correctly?
NO
Connect interface cable correctly. (*2)
YES
Is the connector of interface cable broken?
YES
Use a new interface cable and correctly
connect it.
Yes
(when using scanner on SCSI interface)
Is the SCSI ID set correctly?
NO
Turn OFF the scanner and set the SCSI ID
correctly, then turn ON the scanner again.
(*2)
YES
Does the scanning start after running ON the
scanner again?
YES
The scanner operation is normal.
