3.4ScanningDocumentslongerthanA4size(1)
fi-5120C / fi-5220C Image Scanner Operator Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP

3.4ScanningDocumentslongerthanA4size(1)


1
2 3
1. Load the documents on the ADF paper chute.
For details on loading documents, refer to "2.2 Loading Documents on the ADF for Scanning".
Load the document facing the ADF paper chute. (face down)
2. Adjust the side guides to the document width.
3. Start up ScandAll 21.
For starting up ScandAll 21, select [Programs] - [Scanner Utility for Microsoft Windows] - [ScandAll 21] from [Start].
4. Select fi-5120C or fi-5220C.
From the [Scan] menu, select [Select Source]. Then select the scanner to use and click the [Select] button.
5. Click [Scan To View] on the tool bar.
The [TWAIN Driver] dialogbox appears.
1
2 3
