fi-5900C & fi-5950 CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
18
CLEANING THE CONSUMABLE FEED COMPONENTS (CONT.)
• Open the Pad Cover.
• Remove the Brake Roller by
lifting up on the left side first
and then removing the right
side of the shaft from it’s
mounting hole.
• Clean the rubber surface of
the Brake Roller using a lint
free cloth moistened with F1
Cleaner or isopropyl alcohol.
• Reinstall the Brake Roller
after cleaning.
• Close the Pad Cover.
Notes:
Do not use F2 Cleaner on the Pad, Pick Rollers, Separation Rollers, and
Brake Roller.
Pad Cover
Brake Roller
To Next Page
