5. Capacity table
Capacity tables show each of following values calculated based on the outdoor temperature and
the indoor temperature, under given Airflow Rate (AFR):
For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP)
For heating capacity: Total Capacity (TC) and Input Power (IP)
5-1. Cooling capacity
¢ Model: ARHG72LHTA
AFR
m
3
/h
4,300
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 17.44 14.30 2.86 19.42 14.39 2.91 20.08 15.64 2.93 21.40 15.70 2.96 22.07 16.94 2.97 23.39 16.88 3.01 24.72 17.99 3.03
-10 17.26 14.16 2.87 19.23 14.25 2.92 19.88 15.49 2.93 21.20 15.53 2.96 21.85 16.78 2.98 23.16 16.71 3.01 24.48 17.80 3.03
0 17.10 14.03 3.06 19.05 14.11 3.10 19.69 15.34 3.12 20.99 15.39 3.15 21.64 16.61 3.17 22.95 16.55 3.20 24.24 17.63 3.23
5 17.06 13.99 3.19 19.01 14.07 3.24 19.65 15.30 3.26 20.94 15.34 3.29 21.60 16.58 3.31 22.89 16.51 3.35 24.19 17.59 3.38
10 16.88 13.97 3.59 18.81 14.05 3.65 19.44 15.27 3.67 20.72 15.33 3.70 21.37 16.55 3.72 22.65 16.49 3.76 23.94 17.56 3.80
15 16.40 13.80 3.71 18.25 14.03 3.77 18.89 15.25 3.79 20.12 15.30 3.83 20.74 16.53 3.85 21.99 16.46 3.88 23.23 17.52 3.93
20 16.62 13.93 4.13 18.50 14.17 4.20 19.14 15.40 4.21 20.40 15.45 4.26 21.03 16.69 4.28 22.29 16.62 4.33 23.56 17.70 4.36
25 16.78 13.94 4.90 18.69 14.18 4.98 19.33 15.41 5.00 20.61 15.46 5.05 21.24 16.71 5.08 22.52 16.64 5.13 23.79 17.72 5.18
30 16.45 13.25 5.60 18.33 13.47 5.67 18.96 14.65 5.70 20.19 14.69 5.77 20.82 15.87 5.79 22.07 15.81 5.84 23.32 16.85 5.91
35 15.01 12.95 6.24 16.72 13.24 6.33 17.29 14.40 6.37 18.43 14.44 6.43 19.00 15.60 6.46 20.14 15.53 6.53 21.28 16.55 6.59
40 14.86 12.23 5.91 16.55 12.58 5.99 17.12 13.68 6.03 18.25 13.72 6.08 18.81 14.82 6.11 19.94 14.77 6.18 21.07 15.72 6.24
46 11.84 11.08 5.76 13.19 11.90 5.83 13.63 12.61 5.87 14.52 12.98 5.93 14.98 14.02 5.96 15.89 13.96 6.02 16.78 14.86 6.07
¢ Model: ARHG90LHTA
AFR
m
3
/h
4,300
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 20.19 16.22 3.44 22.49 16.33 3.50 23.25 17.75 3.52 24.78 17.81 3.56 25.55 19.23 3.57 27.08 19.15 3.62 28.62 20.41 3.65
-10 19.98 16.06 3.46 22.27 16.16 3.51 23.02 17.58 3.52 24.55 17.63 3.56 25.30 19.04 3.58 26.82 18.96 3.62 28.34 20.20 3.65
0 19.80 15.91 3.68 22.05 16.01 3.73 22.80 17.40 3.76 24.30 17.46 3.79 25.05 18.85 3.82 26.57 18.77 3.85 28.07 20.00 3.89
5 19.75 15.88 3.84 22.01 15.96 3.90 22.75 17.36 3.93 24.25 17.41 3.96 25.01 18.81 3.99 26.51 18.73 4.02 28.01 19.95 4.06
10 19.55 15.85 4.32 21.78 15.94 4.38 22.51 17.33 4.41 24.00 17.39 4.45 24.74 18.77 4.48 26.23 18.71 4.52 27.71 19.92 4.57
15 18.99 15.66 4.47 21.14 15.92 4.53 21.87 17.31 4.56 23.30 17.35 4.60 24.02 18.75 4.63 25.47 18.68 4.67 26.90 19.88 4.72
20 19.24 15.81 4.97 21.42 16.08 5.05 22.17 17.48 5.07 23.62 17.53 5.12 24.35 18.94 5.15 25.81 18.86 5.20 27.28 20.09 5.25
25 19.42 15.82 5.90 21.64 16.08 5.99 22.39 17.49 6.02 23.86 17.54 6.08 24.60 18.96 6.11 26.07 18.88 6.17 27.55 20.11 6.23
30 19.05 15.03 6.73 21.22 15.29 6.82 21.95 16.62 6.86 23.38 16.67 6.93 24.11 18.01 6.97 25.55 17.94 7.03 27.00 19.12 7.11
35 17.38 14.69 7.50 19.35 15.02 7.61 20.02 16.34 7.66 21.35 16.39 7.74 22.00 17.70 7.77 23.32 17.63 7.85 24.65 18.78 7.93
40 17.21 13.87 7.10 19.17 14.27 7.20 19.82 15.52 7.26 21.13 15.57 7.31 21.78 16.82 7.35 23.09 16.76 7.43 24.39 17.84 7.51
46 13.70 12.57 6.92 15.27 13.50 7.01 15.78 14.31 7.06 16.81 14.73 7.13 17.35 15.91 7.17 18.39 15.84 7.24 19.42 16.86 7.31
- 9 -
DUCT TYPE
ARHG72-90LHTA
