13. Function settings
Perform appropriate function setting locally according to the installation environment.
NOTE:
Incorrect settings can cause a product malfunction.
CAUTION
• Before setting up the switch buttons, discharge the static electricity from your body.
• Never touch the terminals or the patterns on the parts that are mounted on the PCB.
13-1. Local setting switch buttons
¢
Control PCB and switch buttons location
Control PCB of the outdoor unit is located as shown in the following figure.
LED display and button
¢
Switch buttons and the functions
/
SW107
SW108 SW109 SW112 SW110
LED display part
Button part
- 73 -
OUTDOOR UNIT AOHG72-90LRLA
