5-2. Heating capacity
NOTE:
Values mentioned in the table are calculated based on the maximum capacity.
¢ Model: ARHG72LHTA
AFR
m
3
/h
4,300
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-20 -21 10.58 5.57 10.32 5.68 10.07 5.80 9.82 5.91 9.57 6.02
-15 -16 16.21 6.42 15.83 6.56 15.44 6.69 15.06 6.82 14.68 6.96
-10 -11 18.89 6.82 18.44 6.96 18.00 7.10 17.55 7.25 17.10 7.39
-5 -7 20.98 7.11 20.48 7.26 19.98 7.41 19.48 7.56 18.99 7.70
0 -2 22.62 7.19 22.08 7.34 21.54 7.49 21.00 7.63 20.47 7.78
5 3 25.56 7.20 24.95 7.35 24.35 7.50 23.73 7.64 23.13 7.79
7 6 25.83 7.21 25.22 7.36 24.60 7.51 23.99 7.66 23.37 7.81
10 8 27.04 7.16 26.39 7.30 25.74 7.46 25.09 7.60 24.46 7.76
15 10 28.06 7.16 27.39 7.30 26.72 7.45 26.05 7.61 25.38 7.71
20 15 25.25 6.25 24.64 6.37 24.04 6.50 23.44 6.64 22.83 6.72
24 18 25.81 6.21 25.19 6.33 24.58 6.47 23.96 6.61 23.35 6.69
¢ Model: ARHG90LHTA
AFR
m
3
/h
4,300
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-20 -21 12.77 6.65 12.47 6.79 12.16 6.93 11.86 7.07 11.56 7.19
-15 -16 19.57 7.68 19.11 7.84 18.64 8.00 18.18 8.16 17.72 8.31
-10 -11 22.81 8.16 22.27 8.32 21.73 8.49 21.19 8.66 20.65 8.83
-5 -7 25.33 8.50 24.73 8.68 24.12 8.86 23.52 9.03 22.92 9.21
0 -2 27.31 8.59 26.66 8.77 26.00 8.95 25.35 9.13 24.71 9.29
5 3 30.86 8.61 30.12 8.79 29.39 8.97 28.65 9.13 27.92 9.27
7 6 31.19 8.62 30.44 8.80 29.70 8.98 28.96 9.16 28.22 9.28
10 8 32.64 8.56 31.86 8.73 31.08 8.92 30.29 9.09 29.53 9.28
15 10 33.88 8.56 33.07 8.72 32.26 8.91 31.45 9.10 30.65 9.22
20 15 30.48 7.47 29.75 7.61 29.02 7.77 28.30 7.94 27.57 8.04
24 18 31.16 7.43 30.42 7.57 29.67 7.73 28.93 7.90 28.20 8.00
DESIGN & TECHNICAL MANUAL
- 10 -
DUCT TYPE
ARHG72-90LHTA
