Fujitsu GENERAL ARHG72LHTA - Refrigerant Circuit; Models: AOHG72 LRLA and AOHG90 LRLA

4. Refrigerant circuit
4-1. Models: AOHG72LRLA and AOHG90LRLA
Pressure sensor
(High)
Pressure
switch
Strainer
Pressure
sensor
(Low)
25.4mm (1in)
12.7mm (1/2in)
Muffler
Expansion
Valve
3-WAY
Valve
4-WAY
Valve
Pressure
Check Valve
3-WAY
Valve
- 59 -
OUTDOOR UNIT AOHG72-90LRLA
