Ports and operating elem en ts
Install air filter
Make sure that the arrow (a) on the air filter points in the correct direction and that you
reinsert the air filter with the same orientation that it had b efore the cleaning operation.
a
1
1
► Insert the air filter at and angle into the slot (1) and ensure that you feel it click into place.
► Turn the notebook the right way up and place it on a flat surface.
► Reconnect the cables that you disconnected previously.
A26391-K273-Z220-1 -7619 , edition 1 19
