Ports and operating elements
Module
ModulebayModules
The design of your notebook enables the flexible use of noteb ook batteries and drives. The
following modules can be operated in the module bay of your notebook:
• DVD/CD-R/RW drive
• DVD Super Multi D rive
• Second battery
• Blind insert (Weight Saver)
Only use modules designed for your notebook.
Do not use force when installing or removing the module.
Make sure that no foreign objects e nter the module bay.
You c an swap modules during operation. T his means you do not
need to switch off the notebook.
To re place a module, simply click on the corresponding icon in the
task bar and then on Exit or Select - Exit.
The module can now be removed without any further actions being necessary.
Removing a module
1
2
ModuleDriveWei ghtS
aver
► Slide the release mechanism (1) in the direction of the arrow and hold.
► Now p ull the modu le (2) out of the mod ule bay.
20 A26391-K273-Z220-1-7619, edition 1
