Ports and operating elem en ts
Installing a module
► Place the module into t
he module bay so that the contacts enter first.
► Push the module into the module bay until you feel it locking into place.
SIM card
Follow the instructio
ns supplied by the provider of the SIM card.
Inserting t he SIM card
► Switch the notebook off and pull the power plug out of the mains socket.
► Close the LCD screen so that it noticeably locks into place.
► Disconnect all cables connected to the notebook.
► Turn your no tebook over and place it on a s table, sturdy, flat surface. If necessary, l ay a
non-slip cloth on this s urface to prevent the notebook from being scratched.
► Remove the battery (see Section "
Removing the battery", Page 16).
► SlidetheSIMcardintotheslot(1)(withthe
contacts facing upwards) until it engages.
► Slide the clip (a) of the SIM card in the
direction of the arrow (2).
► Reinstall the bat
tery (see "
Installing batt ery", Page 17).
► Turn the notebook the right way up and place it on a flat surface.
► Reconnect the cabl
es that you disconnected previously.
A26391-K273-Z220-1 -7619 , edition 1 21
