Fujitsu LifeBook S6420 Easy Guide

Removing and installing components
during servicing
Removing and installing compo
nents
during servicing
Only qualified technicians should r epair your notebook. U nauthorised
opening or incorrect repair may greatly en danger the user (electric shock,
fire risk) and will invalidate your warranty.
Components
Serv icin g
You may remove and install the components described in this chapter yourself
after consulting the Hotline/Help Desk .
If you rem ove and install components without consulting the Hotline/Help
Desk, t hen the warranty of your notebook will be voided.
Notes on installing and removing boards
and components
• Switch the notebook off and pull the power plug out of the mains socket.
• Always remove the battery.
• Ta ke care whe n you use the locking mechanisms on the battery and any other component .
• Never use sharp objects suc
h as screwdrivers, scissors or knives as leverage to remove covers.
NotesBoardESD
Boards with electrostatic sensitive devices (ESD) are marked with the label
shown.
When handling boards fitted with ESDs, you m ust a lwa ys observe the following
points:
• You must always discharge static build up (e.g. by touching a grounded
object) before working.
• The equipment and tools you use must be free of static charges.
• Remove the power plug from the mains supply before inserting or removing
boards containing ESDs.
• Always hold boards with ESDs by their edges.
• Never touch pins or conductors on boards fitted with ESDs.
A26391-K273-Z220-1 -7619 , edition 1 25

Fujitsu LifeBook S6420 Specifications

General

Bus type	FSB
Stepping	R0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	P8700
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo P8000 Series
Processor socket	Socket 479
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.53 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1066 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	25 W
CPU multiplier (bus/core ratio)	9.5
Number of Processing Die Transistors	410 M
Motherboard chipset	Intel® GM45 Express
HDD speed	5400 RPM
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	320 GB
Display surface	Gloss
Display diagonal	13.3 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Internal memory	2 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	4 GB
Memory layout (slots x size)	1 x 2 GB
Audio system	Realtek ALC269
Front camera resolution (numeric)	1.3 MP
Type	PC
Modem speed	56 Kbit/s
Dimensions (WxDxH)	314 x 234 x 22.4 mm
Compatible operating systems	Microsoft Windows Vista Business/Home Basic
Compliance industry standards	WMI, PXE, BootP
Bluetooth version	2.1+EDR
Networking features	Gigabit Ethernet
Mobile network generation	3G
Trial software	Symantec Norton Internet Security
Pre-installed software	Adobe Acrobat Reader, Application Panel, Display Manager, ShockSensor Utility, Power Saving Utility, Wireless Selector Utility, EasyGuide, Nero Essentials S, Norton Internet Security
Operating system installed	Windows 7 Professional
Optional operating system supplied	Windows XP Professional
Battery capacity	5800 mAh
Battery life (max)	5 h
Number of battery cells	6
TV-out type	S-Video
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	3
CardBus PCMCIA slot type	Type II
Cable lock slot type	Kensington
Password protection type	BIOS
Maximum resolution	1920 x 1200 pixels
Discrete graphics card model	Intel® GMA 4500MHD
Video card features	DualView
Pointing device	Touchpad + Scroll zone
Keyboard key pitch	19 mm
Keyboard keystroke	3 mm
Keyboard number of keys	85
Certification	CE, CE!, FCC Class B, CSA, cUL, UL, RoHS, WEEE, HCT/HCL entry/WHQL, ENERGY STAR 4.0, EPEAT Silver
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 85 %
AC adapter power	80 W
AC adapter input voltage	100 - 240 V
AC adapter output current	4.22 A
AC adapter output voltage	19 V
Battery life with optional 2nd battery	8.5 h
Processor code	SLGFE
Processor ARK ID	37006
Processor package size	35 x 35 mm

Weight and Dimensions

Weight	1700 g
