Fujitsu LifeBook S6420 Easy Guide

Contents
Contents
Innovativetechnology... ............................................................... 1
Notational conventions .................................................................. 2
Importantnotes ........................................................................ 3
Help if problemsoccur ................................................................... 3
Portsandoperatingelements ......................................................... 4
Notebook open . . . ...................................................................... 4
Leftside ................................................................................ 5
Rightside .............................................................................. 5
Rear ................................................................................... 6
Underside . . . . .......................................................................... 6
Switching on the notebook . . . . ........................................................... 7
Switching off the Notebook . . . ........................................................... 8
Statusindicators ........................................................................ 9
Keycombinations ....................................................................... 12
Application keys ........................................................................ 14
Programmingtheapplicationkeys .................................................... 15
Camera (optional) . ...................................................................... 15
Removing andinstalling the battery ....................................................... 16
Removing the battery ................................................................ 16
Installing battery .................................................................... 17
Removing and installing the air filter ...................................................... 18
Air filterremoval .................................................................... 18
Install air filter ...................................................................... 19
Module ................................................................................. 20
Removing a module . . . . . . ........................................................... 20
Installing a m odule .................................................................. 21
SIM card ............................................................................... 21
InsertingtheSIMcard ............................................................... 21
Removing aSIM card ............................................................... 22
Radio components:UMT S (optional)/wireless LAN/Bluetoo th . . . ............................. 22
Switching the wireless components on and off . ........................................ 23
Securityfunctions ....................................................................... 23
Briefoverviewofsecurityfunctions ................................................... 24
Removin
g and installin g components during servicing . . . . .............................
25
Notes on
installing andremovingboards andcomponents ..................................
25
Removin
gandinstalling memorymodules ................................................
26
Removi
ng cover .....................................................................
27
Removi
ng memorymodules ..........................................................
27
Insta
lling amemorymodule ..........................................................
28
Attac
hingthecover ..................................................................
28
Technicaldata ......................................................................... 29
Notebook . . ............................................................................. 29
Battery ................................................................................. 30
Mains adapter .......................................................................... 31
Ind
ex ..................................................................................
32
A26391-K273-Z220-1 -7619 , edition 1

Fujitsu LifeBook S6420 Specifications

General

Bus type	FSB
Stepping	R0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	P8700
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo P8000 Series
Processor socket	Socket 479
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.53 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1066 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	25 W
CPU multiplier (bus/core ratio)	9.5
Number of Processing Die Transistors	410 M
Motherboard chipset	Intel® GM45 Express
HDD speed	5400 RPM
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	320 GB
Display surface	Gloss
Display diagonal	13.3 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Internal memory	2 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	4 GB
Memory layout (slots x size)	1 x 2 GB
Audio system	Realtek ALC269
Front camera resolution (numeric)	1.3 MP
Type	PC
Modem speed	56 Kbit/s
Dimensions (WxDxH)	314 x 234 x 22.4 mm
Compatible operating systems	Microsoft Windows Vista Business/Home Basic
Compliance industry standards	WMI, PXE, BootP
Bluetooth version	2.1+EDR
Networking features	Gigabit Ethernet
Mobile network generation	3G
Trial software	Symantec Norton Internet Security
Pre-installed software	Adobe Acrobat Reader, Application Panel, Display Manager, ShockSensor Utility, Power Saving Utility, Wireless Selector Utility, EasyGuide, Nero Essentials S, Norton Internet Security
Operating system installed	Windows 7 Professional
Optional operating system supplied	Windows XP Professional
Battery capacity	5800 mAh
Battery life (max)	5 h
Number of battery cells	6
TV-out type	S-Video
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	3
CardBus PCMCIA slot type	Type II
Cable lock slot type	Kensington
Password protection type	BIOS
Maximum resolution	1920 x 1200 pixels
Discrete graphics card model	Intel® GMA 4500MHD
Video card features	DualView
Pointing device	Touchpad + Scroll zone
Keyboard key pitch	19 mm
Keyboard keystroke	3 mm
Keyboard number of keys	85
Certification	CE, CE!, FCC Class B, CSA, cUL, UL, RoHS, WEEE, HCT/HCL entry/WHQL, ENERGY STAR 4.0, EPEAT Silver
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 85 %
AC adapter power	80 W
AC adapter input voltage	100 - 240 V
AC adapter output current	4.22 A
AC adapter output voltage	19 V
Battery life with optional 2nd battery	8.5 h
Processor code	SLGFE
Processor ARK ID	37006
Processor package size	35 x 35 mm

Weight and Dimensions

Weight	1700 g
