U41617-J-Z156-1-76 Options Guide 17
4 Preparation
V CAUTION!
Observe the safety instructions in the chapter “Safety notes” on page 11
et seqq. .
4.1 Opening the server
Ê Terminate all applications and shut down the server correctly.
Ê If your operating system has not switched off the server, press the on/off
button.
Ê Pull all power connectors out of the power outlets.
Ê Disconnect all cables on the rear of the server.
Figure 2: Pulling the server out of the rack
Ê Loosen the two knurled screws (1) and pull the server as far as possible out
of the rack.
Ê Press the locking spring (1) on both sides and carefully pull the server
outward.
Ê Pull the server out of the rails and place it on a table, for example.
1
2
