U41617-J-Z156-1-76 Options Guide 21
Main memory Extending/replacing the main memory
5.2 Extending/replacing the main memory
Ê Open the server as described in the chapter “Preparation” on page 17 et
seqq. .
Figure 5: Removing a memory module
Ê Press the holders on either side of the mounting location concerned outward
(1).
Ê If the mounting location was already equipped: pull the memory module out
of the mounting location (2).
Figure 6: Inserting a memory module
Ê Press the holders on either side of the mounting location concerned
outward.
1
1
2
2
2
