U41617-J-Z156-1-76 Options Guide 23
6 Accessible drives
V CAUTION!
Observe the safety instructions in the chapter “Safety notes” on page 11
et seqq. .
One 5.25-inch slimline bay is available for accessible drives.
6.1 Installing an accessible 5.25-inch slimline
drive
The 5.25-inch slimline drives available are CD-ROM and CD-RW/DVD drives.
These drives can be installed in the free 5.25-inch slimline bay.
Ê Open the server as described in the chapter “Preparation” on page 17 et
seqq. .
Figure 7: Removing the dummy cover
Ê Loosen the knurled screw (see circle).
Ê Push the dummy cover inward out of the bay.
