38 Options Guide U41617-J-Z156-1-76
Closing the server Completion
If you have not removed the server from the rack cabinet, please skip this page.
Ê Push the server from the frontside in the extended telescopic rails.
Ê Reconnect all the cables you disconnected beforehand on the rear of the
server.
Figure 20: Installing the server in a rack cabinet
Ê Press in the locking spring (1) on both sides and push the server as far as it
will go into the rack.
Ê Fasten the server in the rack using the two knurled screws (2).
Ê Connect all power plugs to the power outlets.
Ê Press the on/off key to start up the server.
2
1
