RX1330 M4 Operating Manual 97
Technical data
Onboard or integrated controllers
RAID controller PSAS CP400i with "Integrated RAID" (IR)
RAID levels 0 and 1 are supported for internal HDD
configurations.
Modular RAID controller (based on LSI SAS3108)
SAS/SATA HDD/SSD up to 12 Gbit/s SAS, 6 Gbit/s
SATA, 8 ports internal/external
RAID level: 0, 1, 1E, 10, 5, 50, 6, 60
1/2/4 GB cache, optional FBU
Modular RAID controller (based on LSI SAS3508)
SAS/SATA/PCIe HDD/SSD up to 12 Gbit/s SAS,
6 Gbit/s SATA, 8 Gbit/s PCIE, 8 ports internal
RAID level: 0, 1, 1E, 10, 5, 50, 6, 60
2 GB cache, optional FBU
Modular RAID controller (based on LSI SAS3516)
SAS/SATA/PCIe HDD/SSD up to 12 Gbit/s SAS,
6 Gbit/s SATA, 8 Gbit/s PCIE, 16 ports internal /
8 ports external
RAID level: 0, 1, 1E, 10, 5, 50, 6, 60
4/8 GB cache, optional FBU
SATA controller 1x SATA controller integrated on the system board;
up to four SATA HDDs/SSDs can be connected to
the controller. The LSI Embedded MegaRAID
software (Software RAID) supports RAID levels 0, 1,
10.
1x single SATA3 connector for ODD
2x M.2 connector with support for SATA and PCIe
LAN controller 2 x 1Gbit/s LAN connector onboard (RJ45)
Remote Management
Controller
Integrated Remote Management Controller
(iRMC S4/S5), 256 MB DDR3-800 SRAM for video,
IPMI 2.0 compatible
Trusted Platform
Module (TPM)
Infineon / separate module; TCG V2.0 compliant,
SPI support (option)

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
