RX200 S5 Options Guide 67
13 Cabling
13.1 Cabling overview
No. Part no. Description From To
1 A3C40102683 Front VGA cable Front panel board System board
2 A3C40102687 SATA cable ODD Optical Disk Drive
(ODD)
1. SATA
connection
(system board)
2. HDD
backplane
3 A3C40102656 SAS HDD cable Onboard SATA
connection or RAID
controller in slot 3
HDD backplane
(CN1 or CN2)
4 A3C40102678 Front panel cable The control panel System board
5 T26139-
Y3987-V2
iBBU cable iBBU RAID controller
Table 1: Cabling overview
