RX200 S5 Options Guide 69
Cabling Cable diagrams
13.2.2 Cabling for up to 6 HDD modules
Figure 42: Cable diagram for 6 HDD modules with optional RAID controller
Front
panel
CN3
VGA
iBBU
PSU 1
PSU 2
P2
P3
P1
TPM
Front VGA
Slot 2
Slot 1
Front Panel
CPU 2
CPU 1
SATA ODD
JP5
DIMM 1C DIMM 2C DIMM 1B DIMM 2B DIMM 1A DIMM 2A
DIMM 2D DIMM 1D DIMM 2E DIMM 1E DIMM 2F DIMM 1F
Fan 1/2
Fan 3/4 Fan 5/6 Fan 7/8
Fan 9/10
Fan 11/12
iRMC
DVD drive
RAID controller
Slot 3
iBBU connector
PWR
PWR CTRL
System Board
D2786
CN2 CN1
Ch. A Ch. B
Back-
plane
6x HDD
Power
distribution
board
SATA
Power
SAS
Data
Key:
