RX2530 M5 Operating Manual 29
Liquid cooling configuration
I A LC configuration is provided on special release request only.
The quick connectors to connect the LC to the server system are on the rear of
the server.
Figure 5: Quick connectors for LC
1 Quick connector with blue
marking: water inlet
2 Quick connector with red marking:
water outlet
