Fujitsu PRIMERGY RX2530 M5 - Indicator on Hot-Plug PSU

42 Operating Manual RX2530 M5
Product description
3.3.3.2 Indicator on hot-plug PSU
Figure 14: Indicator on hot-plug PSU (AC PSU)
Figure 15: Indicator on hot-plug PSU (DC PSU)
Pos. Indicator Status Description
1
PSU status
indicator
flashing
green
The server is switched off, but mains
voltage is present (standby mode).
green on
The server is switched on and operating
properly.
flashing
orange
An overload has been detected. The
PSU is still running, but failure might be
imminent.
orange on
An PSU failure has been detected.
Possible causes:
– Over/under voltage
– Overheating
– Fan failure
