Fujitsu PRIMERGY RX2530 M5 - Installing 2.5-Inch HDD;SSD Modules; Removing a 2.5-Inch HDD;SSD Dummy Module; Installing a 2.5-Inch HDD;SSD Module

84 Operating Manual RX2530 M5
Operation
6.2.2 Installing 2.5-inch HDD/SSD modules
6.2.2.1 Removing a 2.5-inch HDD/SSD dummy module
Figure 27: Removing a 2.5-inch HDD/SSD dummy module
Ê Press both tabs together (1) and pull the dummy module out of its bay (2).
V CAUTION!
Keep the dummy module for future use.
Always replace dummy modules into unused HDD/SSD bays to comply
with applicable EMC regulations and satisfy cooling requirements.
6.2.2.2 Installing a 2.5-inch HDD/SSD module
Figure 28: Opening the locking lever
Ê Pinch the green locking clips (1) and open the locking lever (2).
