Fujitsu PRIMERGY RX2530 M5 - Overview of the Server

18 Operating Manual RX2530 M5
Product description
3.1 Overview of the server
Figure 1: Server front
Pos. Component
1ODD
2ID card
3 Front panel module (not on 10x2.5-inch version)
4
HDD / SSD / PCIe SSD:
4x 3.5-inch HDD or
up to 8x 2.5-inch HDD/SSD or
2x 2.5-inch PCIe SSD and 8x 2.5-inch HDD/SSD or
4x 2.5-inch PCIe SSD and 6x 2.5-inch HDD/SSD or
10x 2.5-inch SATA HDD / SSD / PCIe SSD
5 Front panel on QRL (only on 10x 2.5-inch version)
