RX2540 M5 Operating Manual 17
3 Product description
This section provides an overview of the server and information on the features
of the PRIMERGY RX2540 M5 server.
The PRIMERGY RX2540 M5 server is available as a rack model.
3.1 Overview of the server
Figure 1: Front side 3.5-inch HDDs (up to 8 HDDs)
Figure 2: Front side 3.5-inch HDDs (up to 12 HDDs)
Pos. Component
1
ID card
I 12x 3.5-inch version: There is an identification sticker placed on
the s
erver top. (For Japan, there is an identification sticker
placed above the quick release lever.)
2ODD
3 Front panel module
4 Space for HDDs (depending on the configuration)
