RX2540 M5 Operating Manual 29
I Depending on the BIOS settings, the shared LAN connector may also be
us
ed as a management LAN connector. For more information, see the
corresponding BIOS Setup Utility reference manual.
I Some of the devices connected require special software (e.g. drivers)
(see documentation for the connected device).
Liquid cooling configuration
I A LC configuration is provided on special release request only.
The quick connectors to connect the LC to the server system are on the rear of
the server.
Figure 9: Quick connectors for LC
1 Quick connector with blue
marking: water inlet
2 Quick connector with red marking:
water outlet
