RX300 S5 Operating manual 13
Preface Features
Hard disk drives
The server is available in the following drive configurations:
● 6*3.5-inch SAS/SATA hard disk drives:
up to six (2x3) HDD modules, each with a 3.5-inch SAS/SATA hard disk drive
with a maximum height of 1 inch. Slot for an optional 3.5-inch DAT or RDX
drive.
Figure 2: RX300 S5 with 6*3.5-inch HDD modules
● 8*2.5-inch SAS/SATA hard disk drives:
up to eight (2x4) HDD modules, each with a 2.5-inch SAS/SATA hard disk
drive with a maximum height of 15 mm. Slot for an optional 3.5-inch DAT or
RDX drive.
Figure 3: RX300 S5 with 8*2.5-inch HDD modules
● 12*2.5-inch SAS/SATA hard disk drives:
up to twelve (3x4) HDD modules, each with a 2.5-inch SAS/SATA hard disk
drive with a maximum height of 15 mm.
Figure 4: RX300 S5 with 12*2.5-inch HDD modules
