58
Operating Manual
T
X120
S
3
S
t
arting up and o
peration
6.2
Openin
g the HDD
cover
Figure 12:
Removing the HDD cover
Ê
Unlock the serv
er (1).
Ê
Remove the HDD cover
(2).
The HDD cover is replaced and the server locked in the reverse order
.
0
1
57
59
