6 Starting up and operation
V CAUTION!
Follow the safety instructions in chapter "Important information" on
page 31.
6.1 Opening the drive cover
Opening the drive cover with locked key
Figure 9: Opening the drive cover with locked key
Ê Rotate the green hook (1) in the drive cover for 90°. As a result, even if the
key is locked, the drive cover can be removed.
Ê Rotate the green hook (2) in the drive cover for 90°. Now, the drive cover
cannot be removed if the key is locked.
/
