22 Options Guide U41604-Z156-1-76
Extending/replacing the main memory Main memory
The table below shows the order in which the memory banks must be equipped:
5.2 Extending/replacing the main memory
Ê Open the server as described in the chapter “Preparation” on page 13 et
seqq. .
Figure 13: Removing a memory module
Ê Press the holders on either side of the mounting location concerned outward
(1).
Ê If the mounting location was already equipped: pull the memory module out
of the mounting location (2).
DIMM_1A DIMM_2A DIMM_1B DIMM_2B
single channel equipped empty empty empty
empty equipped empty empty
empty empty equipped empty
empty empty empty equipped
dual channel equipped empty equipped empty
empty equipped empty equipped
equipped equipped equipped equipped
1
1
2
