34 Options Guide U41604-Z156-1-76
PCI slot assembling Controller in the PCI slots
7.2 PCI slot assembling
Install first those controllers which request a defined slot. Then install the PCI-
X controllers, then the PCI66 and at least the PCI33 controllers.
PCI
bus
type
Quanti
ty
Preferred
slot
Forbidden
slot
1. Controller for defined slots
RemoteView service board S2 LP 33 1 1 2, 3
2. PCI-X controller
3. PCI 66 MHz controller
LSI MegaRaid Zero Channel 66 1 2 1, 3, 4, 5
LSI MegaRaid Two Channel 66 1 2, 3 1, 2, 4, 5
Emulex LP900SL 66 3 1, 3, 4 2
Qlogic QLA2200 66 3 1, 3, 4 2
Intel Pro 1000MT Dual Port 66 4 2, 3, 4, 5
Intel Pro 1000MT Server 66 4 2, 3, 4, 5
4. PCI 33 MHz controller
Promise TX150 SX4 33 1 2
Eicon Diehl Diva Bri-2M 33 2 5, 4, 3, 1
Eicon S94 33 2 5, 4, 3, 1
Madge MK4 33 4 5, 4, 3, 1
Intel Pro 1000MT Desktop 66 2 4, 5
Table 2: PCI slot assembling
