U41604-Z156-1-76 Options Guide 65
Completion Rack model
If you have not removed the server from the rack cabinet, please skip this page.
V CAUTION!
At least two people are required to install the server in the rack cabinet.
Do not use the handles on the rack front cover to lift the server into the
rack.
Ê Lower the server from above onto the extended telescopic rails.
Figure 52: Installing the server in a rack cabinet
Ê Screw the telescopic rails onto the left-hand side (one screw) and right-hand
side (two screws) of the server.
Ê Reconnect all the cables you disconnected beforehand on the rear of the
server.
Ê Press in the locking spring on both sides and push the server as far as it will
go into the rack.
2
