Fujitsu PRIMERGY TX150 S4

24 Options Guide U41629-J-Z156-2-76
Rack model Preparation
Figure 8: Loosening the screws
Ê Unlock the top cover by removing the two screws on the server rear (1).
Ê Push the top cover approxiately 2 cm to the rear (2).
Ê Remove the top cover (3).
2
3
1
2
