TX200 S6 Service Supplement 51
5 Appendix
5.1 Board layout
I The board layout of the system board is described in the Technical
Manual of the system board D2799.
5.1.1 Front panel module
Part number: C26361-K644-Z833
1 Connector front panel cable
2 Connector USB cable
Ԙ
ԙ
