Fujitsu RAID 0/1 SAS based on LSI MegaRAID - Modular RAID 3 Gb;s (SAS1.0) Controllers; RAID 0;1 SAS MegaRAID (D2507) Controller

Modular RAID Controllers 15
3 Modular RAID 3Gb/s (SAS1.0)
3.1 RAID controller "RAID 0/1 SAS based on
LSI MegaRAID (D2507)"
V ATTENTION!
Make sure you observe the safety notes in chapter "Important
information" on page 9.
The RAID controller "RAID 0/1 SAS based on LSI MegaRAID" is designed to
drive the server's internal disk drive. The RAID stack is based on LSI
MegaRAID
®
and offers powerful data throughput, extensive fault-tolerance and
easy-to-use management.
Figure 2: "RAID 0/1 SAS based on LSI MegaRAID" controllers 1068 (A) and 1064 (B)
A
B
