Modular RAID Controllers

Modular RAID 6Gb/s (SAS2.0)

4.3.3 Connectors and indicators

The following figure shows the location of the connectors and indicators on the

SAS RAID controller.

1iBBU 4LED

2 SAS cable connectors 5 iBBU connector

3 SDB connector
