Fujitsu RAID 0/1 SAS based on LSI MegaRAID User Manual

Modular RAID Controllers 77
Modular RAID 12Gb/s (SAS3.0)
5.1.3 Connectors and indicators
The following figure shows the location of the connectors and indicators on the
SAS RAID controller.
Figure 24: "PRAID EP400i / EP420i" board layout
1 SAS cable connectors
2 TFM (optional)
3 FBU connector on TFM
4 HDD LED connector
5 RAID controller indicator
