72
Modular RAID Controllers
Modular RAID 6Gb/s (SAS2.0)
4.6.3 Connectors and indicators
The following figure shows the location of the connectors and indicators on the
SAS controller.
Indicators
1 Indicators
LED Description
L1 (H322) Heart Beat
L2 (H321) Error for Power PC1
L3 (H320) Error for Power PC0
