3. Local Port Operation
Button Function
Setup
Access the Setup dialog box and configure the OSD
interface.
Commands Access the Commands dialog box.
Name Name of server.
EID Unique ElectronicID in a module.
Port The port to which a target device is connected.
Viewing and selecting ports and servers
Use the Main dialog box to view, configure and control target devices in the
switching system. You may view the target devices by name, port or by the
unique Electronic ID (EID) embedded in each IQ module. You will see an OSD-
generated port list by default when you first launch the OSD.
The Port column indicates the port to which a target device is connected.
Selecting a target device
Use the Main dialog box to select a target device. When you select a target
device, the switch reconfigures the local keyboard and mouse to the settings for
the selected target device.
To select a target device:
Double-click the target device name, EID or port number.
-or-
If the display order of your list is by port (the Port button is depressed), type the
port number and press Enter.
-or-
If the display order of your list is by name or EID (the Name or EID button is
depressed), type the first few letters of the name of the target device or the EID
number to establish it as unique and press Enter.
To select the previous target device:
Press Print Screen and then Backspace. This key combination toggles you
between the previous and current connections.
590-1035-640A
10
