Fujitsu s3-0801 - 7 Technical Specifications

7. Technical Specifications
7. Technical Specifications
Server Ports
Number 16 - s3-1601 switch 8 - s3-0801 switch
Type PS/2, Sun, USB and Serial
Connectors 8-pin modular
Sync Types Separate horizontal and vertical
Plug and Play DDC2B
Video Resolution
640 x 480 @ 60 Hz 800 x 600 @ 75 Hz 960 x 700 @
75 Hz 1024 x 768 @ 75 Hz 1280 x 1024 @ 75 Hz
1600 x 1200 @ 60 Hz
Supported Cabling
4-pair UTP CAT 5 or CAT 6, 150 feet (45 meters)
maximum length
Dimensions
Form Factor 1-U rack mountable
Height x Width x Depth 1.72 x 17.00 x 6.5 in (4.37 x 43.18 x 16.51 cm)
Weight (without cables) 4.2 lbs (1.9 kg)
SETUP Port
Number 1
Type RS-232 serial
Connector DB9 male
Local Port
Number 1
Type PS/2, USB and VGA
USB Device Port
Number 2
Table 7.1: s3-0801/1601 Switch Product Specifications
590-1035-640A
45
