3. Local Port Operation
If new IQ modules are discovered by the switch, the on-screen list will be automatically
updated. The mouse cursor willchange into an hourglass during the update. No mouse
or keyboard input willbe accepted until the list update is complete.
To assign names to target devices:
1. In the Names dialog box, select a target device name or port number and
click Modify to open the Name Modify dialog box.
2. Type a name in the New Name box.
• Names must be between 1 and 15 characters in length
• Names may have any combination of upper/lower case letters and
digits, but must have at least one letter
• Names may not have punctuation, except for hyphens
3. Click OK to assign the new name.
4. Repeat steps 1-3 for each target device in the system.
5. Click OK in the Names dialog box to save your changes.
-or-
Click X or press Escape to exit the dialog box without saving changes.
Changes made in the Names Modify dialog boxare not saved to the switch until you click
OK in the Names dialog box.
If an IQ module has not been assigned a name, the EID isused as the default name.
3.3 Commands Dialog Box Functions
From the OSDinterface Commands dialog box, you can manage your switching
system and user connections, enable the Scan mode and update your firmware.
Features Purpose
Scan Enable
Begin scanning your target devices. Set up a target device list
for scanning in the Setup dialog box. You must have at least
two target devices selected in the Setup - Scan List menu to
enable target scanning.
User Status View and disconnect users.
Table 3.6: Commands to Manage Routine Tasks for Your Target Devices
590-1035-640A
18
