4.3 The Explorer Window
Number
Description
2 OBWI tabsused to displayconnections, status and configure the appliance.
3
Showsconnected IQ modules, including Status, Server (which is a hyper link
allowing access to the target server selected), EID and Path to targets
connected to the switch.
Viewing and terminating user sessions
You may view and disconnect the current active user connections using the
Status tab in the OBWI. You can view the session type, the server name or IQ
module to which they are connected and their system address. In addition to
disconnecting a user session, the switch also allows one user to take control of a
server currently being used by another user.
To disconnect a user session:
1. Click the Status tab in the OBWI. A list of users and their connection
information appears.
2. Click the checkbox for one or more users that you wish to disconnect.
3. Click the Disconnect Session button. A message appears prompting you to
confirm the disconnect command.
4. Click OK to disconnect the user.
-or-
Click Cancel to exit without completing the disconnect command.
The appropriate level of access isrequired to disconnect a user. If you do not have
permission to disconnect a user, the checkbox next to that user will be disabled.
Managing the switch OBWI
The s3-0801/1601 switch OBWI provides several configuration options to tailor
the switch to your specific application.
Managing users
The switch OBWI provides local and login security through administrator-defined
user accounts. By selecting the Configure tab and then selecting Users on the
side menu bar, administrators may add and delete users, define user preemption
and access levels and change passwords.
590-1035-640A
25
