Burner Assembly - Parts (Common)
2-40-613 1.5 HP 115/230/60/1 Burner Motor 3450 RPM 40 18.18
2-40-615 1.5 HP 230/460/60/3 Burner Motor 2850/3450 RPM 31 14.09
2-40-621 3.0 HP 230/460/50/60/3 Burner Motor 2850/3450 RPM 43 19.55
2-12-014 Pyrex Plate Glass 1 " - 4 -100 HP 0.1 0.05
2-45-025 Bakelite Terminal 90° for Electrode 0.05 0.02
2-45-026 Bakelite Terminal Straight for Electrode 0.05 0.02
2-45-017 Ignition Wire - per foot 0.01 0
2-11-080 Burner Scroll Casting - 80 & 100 HP 65 29.55
5-20-061 Burner Scroll Casting - 40, 50 & 60 HP 50 22.73
Burner Fans: Size HP Applicable Fuel Hz.
2-30-421 8-3/8 x 2-1/2 x 1 40-50 Propane or nat. Gas 50/60 3.00 1.36
60 Propane or nat. Gas 50/60 3.00 1.36
2-30-826 9-15/16 x 3-1/2 x LO75 80
2-30-559 9-15/16 x 3 x LO75 100
*When ordering burner fans, check for the correct part number on the back of the fan plate.
Burner Assembly - Gas
2-40-082 Ignition Transformer - Gas 115/60 9.5 4.32
2-45-026 Straight Bakelite Terminal 0.03 0.01
4-45-010 Ignition Cable with 90° Bakelite Terminal 0.5 0.23
2-20-033 Ignition Electrode 0.4 0.18
2-30-118 Air Switch 80-100 HP 0.72 0.33
5-20-018 Burner Plate Gas - 30-60 HP 1 0.45
5-10-398 Burner Plate Gas - 80 HP 1 0.45
5-10-399 Burner Plate Gas -100 HP 1 0.45
7-20-094 Air Deflector - Gas 80 & 100 HP 65 29.55
7-20-092 Air Deflector - Gas 40 - 60 HP 45 20.45
2-40-533 Gas Pressure Switch High-Low 3.25 1.48
2-30-298 1/2" Pilot Gas Valve (80-100 HP) 1.5 0.68
2-30-312 1-1/2" Gas Valve V5055A (40-60 HP) 10.7 4.86
2-30-313 2" Gas Valve V5055A (80-100 HP) 9.85 4.48
2-30-3003 Modulating Butterfly Valve (40-60 HP)
2-30-3020 Modulating Butterfly Valve (80-100 HP)
2-30-303 1-1/2" Main Gas Valve - V48A 4.5 2.05
2-40-253 Gas Valve Body - P.O.C V5055C (40-60 HP) 11.5 5.23
2-40-254 Gas Valve Body - P.O.C V5055C (80-100 HP) 10.5 4.77
2-40- High-Low-Off Gas Valve Body 80 HP
2-40- HIgh-Low-Off Gas Valve Body 100 HP
2-40-214 Actuator Valve Body 13.70 6.23
2-40-220 Actuator Valve Body w/Proof of Closure Switch 12.8 5.82
2-30-583 High-Low-Off Gas Valve Actuator 80 and 100 HP
2-30-402 1-1/4" Vent Valve - 120V Normally Open 4.7 2.14
2-30-401 1" Vent Valve - 120V Normally Open 4.3 1.95
2-30-198 1/8" Gas Cock (Pet Cock) 0.25 0.11
2-30-111 1/2" Pilot Gas Cock 0.6 0.27
2-30-115 1-1/2 " Main Gas Cock 4.8 2.18
2-30-110 2" Main Gas Cock 16.8 7.64
2-30-102 1/2" Gas Pressure Regulator RV 48 0.7 0.32
2-30-107 1-1/2"Gas Pressure Regulator - RV 81 4.8 2.18
2-30-108 2" Gas Pressure Regulator - RV 91 8.5 3.86
7-20-298 Natural Gas Orifice - 40 HP 4 1.81
7-20-299 Natural Gas Orifice - 50 HP 4 1.81
7-20-300 Natural Gas Orifice - 60 HP 4 1.81
7-20-093 Natural Gas Orifice - 80 HP 4.5 2.04
7-20-302 Natural Gas Orifice - 100 HP 4.5 2.04
7-20-275 Propane Orifice - 40 HP 4 1.81
Misc. Propane Orifice - 50 hP 4 1.81
VMP IOM
49
Parts and Warranty
Part No. Description Approx. Net Weight
(lbs) (kgs)
