Specifications
Models VMP 40 49.5 50 60 80 100 130 150
Unit Horsepower 40 49.5 50 60 80 100 130 150
Boiler Connections
Steam Outlet 15 PSI - 150# Flanged IN 4 4 4 4 6 6 * 6 * 6
MM 101 101 101 101 152 152 203 203
Steam Outlet 150 PSI IN NPT 3 3 3 3 3 3 4 4
MM 76 76 76 76 76 76 101
Feedwater Inlet IN NPT 1 1 1 1 1 1.25 1.25 1.25
MM 25 25 25 25 25 31 32 32
Blowdown Outlet (2) IN NPT 1.5 1.5 1.5 1.5 1.5 2 2 2
MM 38 38 38 38 38 51 51 51
Water Column Blowdown IN NPT 1 1 1 1 1 1 1 1
MM 25 25 25 25 25 25 25 25
Surface Blowdown IN NPT .75 .75 .75 .75 .75 .75 .75 .75
MM 19 19 19 19 19 19 19 19
Safety Valve 150 PSI Inlet IN NPT .75 1 1 1 1.25 1.25 1.5 1.5
MM 19 25 25 25 31 31 38 38
Safety Valve 150 PSIOutlet IN NPT 1 1.25 1.25 1.25 1.5 1.5 2 2
MM 25 31 31 31 38 38 51 51
Safety Valve 15 PSI Inlet (2) IN NPT 1.25 1.25 1.25 1.25 1.5 1.5 2 2
MM 31 31 31 31 38 38 51 51
Safety Valve 15 PSI Outlet IN NPT 1.5 1.5 1.5 1.5 2 2 2 2
MM 38 38 38 38 51 51 51 51
Natural Gas Connection IN 1.5 1.5 1.5 2 2 2 2 2
MM 38 38 38 51 51 51 51 51
Light Oil Connection IN .25 .25 .25 .25 .25 .25 .375 .375
MM6666 669.59.5
Burner Motor (Gas) HP 1.5 1.5 1.5 1.5 3 3 10 10
KW 1.1 1.1 1.1 1.1 2.2 2.2 7.5 7.5
Burner Motor (Oil/Combo) HP 2 2 2 2 3 3 10 10
KW 1.5 1.5 1.5 1.5 2.2 2.2 7.5 7.5
Approximate Weights
Shipping Weights (approx.) LB 5775 6550 6575 7370 8000 9500 12350 12350
KG 2620 2972 2980 3340 3630 4310 5600 5600
Operating Weight (approx.) LB 6720 8850 8209 9227 11760 14525 20135 20135
KG 3050 4015 3720 4190 5330 6590 9130 9130
**Ratings Sea Level to 3000 FT. (914 M)
Output 1000 BTU/HR 1340 1656 1673 2009 2678 3347 4353 5022
1000 KCAL/HR 338 417 422 506 675 843 1097 1266
Steam Output LBS/HR 1380 1708 1725 2070 2760 3450 4485 5175
KG/HR 626 775 783 939 1252 1565 2035 2348
Water Content GAL 172 274 242 270 383 518 810 810
LITERS 651 1038 916 1022 1450 1960 3066 3066
Approximate Fuel Consumption at Rated Capacity+
Natural Gas FT
3
/HR 1595 1972 1992 2392 3188 3985 5200 5978
M
3
/HR 45 56 56 68 90 113 147 169
LP Gas FT
3
/HR 638 788 797 957 1275 1594 2080 2391
M
3
/HR 18 22 23 27 36 45 59 68
Light Oil GPH 11.0 13.9 14.0 17.0 22.8 28.0 37.0 42.0
LPH 41.6 52.6 53 64.3 87 106 140 159
Gas Pressure Required
Standard Burners Min. IN W.C. 7 7 7 7 9 9 40 40
Gas Pressure Required
Standard Gas Train Max. IN W.C. 13 13 13 13 27 27 5 psig 5 psig
Electrical Requirements/Amps for Burner Motors
208V, 50/60 CY, 3 Phase (Gas/Oil) 6.6/7.5 6.6/7.5 6.6/7.5 6.6/7.5 10.6 10.6 30.8 30.8
230V, 50/60 CY, 3 Phase (Gas/Oil) 6.0/6.8 6.0/6.8 6.0/6.8 6.0/6.8 9.6 9.6 28 28
460V, 50/60 CY, 3 Phase (Gas/Oil) 3.0/3.4 3.0/3.4 3.0/3.4 3.0/3.4 4.8 4.8 14 14
* Steam separator or dual steam nozzle design required.
**Ratings - From 0 PSIG and at 212 Degrees F and KG/HR - From 0 KG/CM
2
and at 100 Degrees C +Consumption based on natural gas 1000 BTU/FT3;
Propane 2500, and Light Oil 140,000 BTU/GAL.
vmpstd-pds-2010-1008
NOTE: 7” - 11” wc gas pressure is required during run for 40-60 HP boilers with standard burners. 9”-11” wc gas pressure is required during run for 80-100 HP boilers with
standard CSD-1 burners, 40” W.C. is required for 130-150 HP
Specifications & dimensions are approximate. We reserve the right to change without notice.
