FULTON VSRT 50 - Page 18

2  INSTALLATION
© Fulton 2018
2-8
VSRT_IOM_2018-1213
Figure 5 - 20-HP Model VSRT Dimensions - Right Side
View (All dimensions in inches)
FRONT VIEW
RIGHT SIDE VIEW
DRAWN BY:
CHECKED BY:
B.O.M. REVIEW: APPROVED BY:
ELECTRICAL REVIEW:
MECHANICAL REVIEW:
REVISIONDRAWING NUMBER
JOB NUMBER:
PROJECT NAME:
PROJECT MANAGER:
DESCRIPTION:
VSRT-20 GAS FIRED MODULATED STEAM BOILER
(150 PSI)
9-SR-020312 - PDS
-
T. KENNEDY
11/16/2017
N/A
N/A
W.W.
11/28/2017
N/A
E.B.W.
11/28/2017
This design and drawings are
proprietary and are the
exclusive property of The
Fulton Companies. The
corporation
does not permit
their use except with prior
written consent.
The items shown in this
drawing may be covered by
one or more patents of The
Fulton Companies.
SHEET 1 OF 1
THIRD ANGLE PROJECTION
TOLERANCES
FRACTION &
WHOLE VALUE
(1) PLACE DEC.
(2) PLACE DEC.
1/8
UNLESS OTHERWISE NOTED
DIMENSIONS ARE IN INCHES
 0.03
(3) PLACE DEC.
SURFACE FINISH
250 MICRO-INCHES
 0.005
 0.5 DEGANGLE
 0.015
Fulton Steam Solutions, Inc.
F
u
l
o
t
n
SEE
NOTE
9
SEE NOTES 3 AND 11
NOTES
:
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
STE
AM OUTPUT LB/HR: FROM 0 PSIG AT 212°F (0 KG/CM² AT
100
°C)
ALL
CLEARANCES ARE FACTORY RECOMMENDATIONS. CONSULT
LOC
AL JURISDICTION FOR EXACT CODE COMPLIANCE.
FUL
TON RECOMMENDS MINIMUM CLEARANCE OF 36" IN FRONT
OF
ELECTRICAL PANELS.
FUL
TON RECOMMENDS 36" CLEARANCE BETWEEN INSPECTION
OPE
NINGS OF ALL BOILERS, 18" CLEARANCE OF HANDHOLES,
AND
14" FROM EXHAUST STACK.
PLE
ASE REFER TO THE O&M MANUAL FOR ADDITIONAL
INF
ORMATION REGARDING CLEARANCES AND INSTALLATION
INS
TRUCTIONS.
ALL
DIMENSIONS INSIDE ( ) DENOTE REFERENCE DIMENSIONS.
ALL
DIMENSIONS INSIDE  DENOTE OVERALL DIMENSIONS.
WE
RESERVE THE RIGHT TO CHANGE SPECIFICATIONS
AND
/OR DIMENSIONS. ALL INFORMATION IS SUBJECT
TO
CHANGE BASED ON ADDITION OF ANY OPTIONAL
EQU
IPMENT AND/OR ACCESSORIES. PLEASE CONSULT THE
FAC
TORY FOR PROJECT SPECIFIC ESTIMATES IF
ADD
ITIONAL OPTIONS OR ACCESSORIES ARE REQUIRED.
RE
COMMENDED STACK RUN IS MINIMUM 24" STRAIGHT OFF
TH
E REAR OF THE BOILER, PRIOR TO MAKING A
DIR
ECTIONAL CHANGE.
LO
CAL CODES CAN SUPERCEDE FULTON RECOMMENDED
CLE
ARANCE.
*SI
ZE AND/OR TYPE DEPENDS ON TRIM PRESSURE.
MAX ALLOWABLE WORKING PRESSURE:
BOILER OUTPUT:
MINIMUM INCOMING GA
S PRESSURE:
150 PSI
670,000 BTU/HR
690 LBS/HR
65 SQ. FT.
112 GAL.
2,711 LBS.
3,645 LBS.
3,281 LBS.
EQUIPMENT SPECIFICATION CHART
APPROXIMATE FLOODED
WEIGHT:
MINIMUM DRAFT REQUI
REMENT:
BURNER TURNDOWN:
3,939 LBS.
4:1
-0.25" W.C.
APPROXIMATE SHIPPIN
G WEIGHT:
APPROXIMATE OPERATING WEIGHT:
APPROXIMATE DRY WEIGHT:
WATER CAPACITY (OPERATING):
NET EFFECTIVE HEATING SURFACE:
STEAM OUTPUT/MIN. SRV CAPACITY:
800 CU FT/HR
BOILER INPUT:
3" W.C.
BOILER INPUT: (NATURAL GAS)
800,000 BTU/HR
CUSTOMER CONNECTIONS
ITEM DESCRIPTION SIZE TYPE
A FEED WATER INLET 1" N.P.T.
B BLOWDOWN OUTLET
1 1/4"
N.P.T.
C STEAM OUTLET*
2" N.P.T.*
D EXHAUST STACK
8"
- - -
E
SAFETY RELIEF VALVE* 1"
N.P.T.
F
FUEL IN
LET
1" N.P.T.
G WATER COLUMN DRAIN 1" N.P.T.
H SIGHT GLASS DRAIN
1/4"
N.P.T.
J WATER SAMPLE PORT
1/4"
N.P.T.
K STEAM SAMPLE PORT
1/4"
N.P.T.
L
SURFACE BLOWDOWN (PLUGGED) 3/4"
N.P.T.
M
HIGH WATER PROTECTION (CAPPED)
3/4"
N.P.T.
N SINGLE SOURCE POWER
- - -
N.P.T.
P COMBUSTION AIR INLET
6"
- - -
R
AUXILIARY WATER COLUMN (CAPPED)
1"
N.P.T.
ELECTRICAL REQUIREMENTS
VOLTAGE OPERATING FLA
120/1/60
10 AMPS
NOTE: OPERATING FULL LOAD AMPERAGE (FLA)
R
EFERS TO THE BOILER'S RATED CURRENT DRAW
AT HIGH FIRE.
21 1/16
7 1/16
32 1/2 (MINIMUM WIDTH)
60 9/16
58 7/16
-
INITIAL RELEASE
- - - - -
REVISION HISTORY
REV REVISION DESCRIPTION B.O.M. ELEC. ENG. MECH. ENG CHECKED APPROVED
110
CLEARANCE REQUIRED
FOR BURNER REMOVAL
82 3/4
(FUEL INLET)
(85 5/8)*
(STEAM
OUTLET)
57 5/8
(AIR INLET)
79 1/8
(MIN HEIGHT)
K
J
G
N
P
E
C
F
5
(BOTTOM BLOWDOWN)
22 3/8
(FEEDWATER)
51
(EXHAUST
STACK)
80 7/8( *)
(S.R.V.)
85 5/8*
B
A
R
L
D
M
7 1/8
H
