FULTON VSRT 50 - Page 21

INSTALLATION  2
Questions? Call (315) 298-5121, or visit us online at www.fulton.com
2-11
VSRT_IOM_2018-1213
RIGHT SIDE VIEW
RIGHT SIDE VIEW
DRAWING NUMBER
REV
-
VSRT-30 HIGH PRESSURE WITH LOW PRESSURE
OPENINGS (150 PSI) MODULATED STEAM BOILER
DESCRIPTION:
DRAWN BY:
T. KENNEDY
CHECKED BY:
B.O.M. REVIEW
MECH. ENG:
ELEC. ENG:
APPROVED BY:
JOB NUMBER:
PROJECT NAME:
PROJECT MANAGER:
This design and drawings
are proprietary and are the
exclusive property of
Fulton Group N.A., Inc.
The corporation does not
permit their use except
with prior written consen
t.
The items shown in this
drawing may be covered by
one or more patents of
Fulton Group N.A., Inc.
1 OF 1
THIRD ANGLE PROJECTION
Fulton Group N.A., Inc
972 Centerville Road
Pulaski, New York USA 13142
4/4/2017
UNLESS OTHERWISE NOTED
DIMENSIONS ARE IN INCHES
R
SHEET 1 OF 1
(1) PLACE DEC.
 0.03
(2) PLACE DEC.
 0.015
(3) PLACE DEC.
 0.005
ANGLE
 0.5 DEG
SURFACE FINISH
250 MICRO-INCHES
TOLERANCES
FRACTION &
WHOLE VALUE

1/8
-
REVISION HISTORY
REV REVISION DESCRIPTION B.O.M. ELEC. ENG MECH. ENG CHECKED APPROVED
L
M
A
D
B
87 3/8
81 5/8( *)
(S.R.V.)
22 5/16
(FEEDWATER)
51
(EXHAUST STACK)
5
(BOTTOM BLOWDOWN)
L
M
A
D
B
87 3/8
81 5/8( *)
(S.R.V.)
22 5/16
(FEEDWATER)
51
(EXHAUST STACK)
5
(BOTTOM BLOWDOWN)
Figure 8 - 30-HP Model VSRT Dimensions - Right Side
View (All dimensions in inches)
