2  INSTALLATION
© Fulton 2018
2-10
VSRT_IOM_2018-1213
Figure 7 - 30-HP Model VSRT Dimensions - Front View
(All dimensions in inches)
FRONT VIEW
B
DRAWING NUMBER
REV
9-SR-030111 - PDS GLEN
-
VSRT-30 HIGH PRESSURE WITH LOW PRESSURE
OPENINGS (150 PSI) MODULATED STEAM BOILER
DESCRIPTION:
DRAWN BY:
T. KENNEDY
CHECKED BY:
J.B.
B.O.M. REVIEW
MECH. ENG:
W.W.
ELEC. ENG:
APPROVED BY:
N/A
E.B.W.
N/A
JOB NUMBER:
PROJECT NAME:
PROJECT MANAGER:
This design and drawings
are proprietary and are the
exclusive property of
Fulton Group N.A., Inc.
The corporation does not
permit t
heir use except
with prior written consent.
The items shown in this
drawing may be covered by
one or more patents of
Fulton Group N.A., Inc.
1 OF 3
THIRD ANGLE PROJECTION
Fulton Group N.A., Inc
972 Centerville Road
Pulaski, New York USA 13142
2/16/2017
2/24/2017
2/24/2017
2/24/2017
UNLESS OTHERWISE NOTED
DIMENSIONS ARE IN INCHES
R
SHEET 1 OF 3
(1) PLACE DEC.
 0.03
(2) PLACE DEC.
 0.015
(3) PLACE DEC.
 0.005
ANGLE
 0.5 DEG
SURFACE FINISH
250 MICRO-INCHES
TOLERANCES
FRACTION &
WHOLE VALUE

1/8
-
REVISION HISTORY
REV REVISION DESCRIPTION B.O.M. ELEC. ENG MECH. ENG CHECKED APPROVED
49 1/4
(AIR INLET)
(74)
(FUEL INLET)
79 1/16
(MINIMUM HEIGHT)
86 3/8
(STEAM OUTLET)
G
J
H
N
110
CLEARANCE REQUIRED
FOR BURNER REMOVAL
K
